Class 4 MOT Lift 4 Post 4 Tonne Lifting Capacity 4.65m

This Class 4 Electro-hydraulic 4-post MOT lift from Boston Garage Equipment is manufactured in Europe. It has a 4-tonne lifting capacity, 4.65m platforms and supports a range of accessories.

FEATURES & BENEFITS:

• Reinforced drive-up ramps / drive-over plates
• Drive-through or reverse-off configurations
• Heavy duty, high quality platforms & reinforced substructure
• Wide 630mm platforms for safer testing of larger vehicles
• Hydraulics & motor on outside edge of front column for maximum working space
• Safety ladder-racks on all posts
• Safety switches and lock release solenoids mounted internal of the crossbeam to avoid potential damage
• Cross beam pulley covers
• Control system and safety electric solenoids all made in UK
• Ruggedised torch controls
• 24V APC / inspection lamp outlets at each corner
• GARAGE EQUIPMENT FINANCE OPTIONS ARE AVAILABLE
• 24 MONTHS WARRANTY

OPTIONAL EXTRAS AND ACCESSORIES

• Play Detectors: PD303 hydraulic integrated twin-plate play detectors with dual controls on lift keypad and remote torch
• Turning Plates: Recessed with nylon runners (no metal-on-metal contact with platform)
• Any Post Control (APC): Separate magnetic lift control keypad can be placed on any other post for flexible operation
• Wireless Torch: For easier vehicle inspection and play detector operation
• LED Lighting Kit: Four 2m LED Strips for complete vehicle underside illumination
• High Speed Lifting Pack: Reduces lifting time to 25 seconds
• Jacking Beams: Compatible with our range of jacking beams up to 3 Tonnes (manual or pneumatic)

Please call us on 01302 203 888 to discuss your requirements and place your order.

UK MOT Approval	Class 4
Power Supply	3PH / 415VAC – 2.6kW
Operation	Electro-hydraulic
Control	Membrane keypad control panel with single button descent operation, emergency stop and main power switch
Installation	Surface mount or recessed configuration
Platform Width & Length	630mm / 4.65m
Lifting Height	1.86m
Max Height, Length & Width	2.37m / 5.88m / 3.19m
Max Lifting Capacity	4 Tonne
Lock Release Mechanism	Electric solenoids (no air required)
Air Outlets	Between Platforms (if connected)



NOTE: image is for illustration purposes only.
