Class IV Pit MOT Bays FROM £19,995
At Concept Garage Equipment we understand that space may be limited, or you may have ample space either way your dedicated project manager will advise you on the best most cost-effective way to install your new DVSA Approved MOT Testing Equipment. We have a wealth of experience within the MOT industry giving you the confidence that what you need can be done the right way.
You may not have the height required for DVSA regulations or the length you need to install a Class 4 MOT Bay but don’t worry if there is a way, we will find it for you. MOT bays come in many configurations such as pit style if height is an issue or four post lift or even a scissor lift if the width is a problem. They can also be installed within a recess or surface mounted. You may be looking for an OPTL (One Person Test Lane) or ATL (Automated Test Lane) or even a TPTL (Two-person Test Lane). Whatever you need we have it for you.
There are many ways to lay out an MOT bay. That may be inline, side by side or even drive-through. We will find the best most cost-effective option for you to retain as much space as possible for other equipment like tyre changers or wheel balancers making your garage or workshop as profitable as possible.
All our MOT bay packages come with free on-site measuring, design, and project management from your dedicated project manager. All our garage equipment is European-made and installed by our trained and experienced installation engineers who will give you all the on-site training you need once your equipment is installed. Leaving you confident in using your new MOT equipment.
We also offer an extensive industry-leading aftersales service. Our job doesn’t end when your installation is complete, and you are signed off by DVSA. We are with you every step of the way up to and way beyond installation. If you need any help or advice, we will be right by your side.
Our Class 4 PIT MOT Bay covers all you need for MOT testing on four-wheel vehicles including cars, motor caravans, taxis and goods vehicles (up to 3,000kg design gross weight), including, roller brake tester and headlamp beam tester, Pit play detector, Jacking beam & radius turn plates.
CLASS 4 MOT PIT BAY PACKAGE INCLUDES:
- Play detector (stand-alone)
- Radius turn plates
- Manually operated Jacking beam
- Roller brake tester
- Combi Emissions machine
- Headlight beam tester
- Decelerometer
- MOT ancillary pack/signage
- MOT Bay Project management including DVSA CAD drawing and DVSA application
OPTIONAL EXTRAS:
- Roller brake tester in ground cassette
- Groundworks
- Classes 1 & 2 RBT adaption kit
- Steel pit liner (if required)
For a full MOT Bay design and installation including supply of all equipment needed, groundwork, full testing and staff training, or for any MOT Bay or MOT Equipment advice or information please call us today on 0113 469 0572 or use the contact form.
Showing all 7 results
-
Roller Brake Tester (RBT) Class 4
Read more -
Headlight Beam Tester
Read more -
Brain Bee Emissions Tester
Read more -
Play Detector Stand Alone for Steering and Suspension
Read more -
MOT Tools and ancillaries
Read more -
Combined Smoke and Gas Vehicle Emissions Analyser Wireless
Read more -
Sale!
Further Reduced
Combined Petrol and Diesel Vehicle Emissions Analyser
£5,250.00 +VAT Add to basket
What vehicles are covered by a Class 4 MOT Bay?
The class of MOT Bay depends on the type of vehicles your garage intend to work on, as per the gov.uk website.
As shown in the table below, the Class IV MOT Bays cover a large percentage of the standard vehicles on the UK roads today and also a few that may surprise you.
Vehicle | Vehicle class | Age first MOT needed (years) |
3-wheeled vehicles (over 450kg unladen weight) | 4 | 3 |
Cars (up to 8 passenger seats) | 4 | 3 |
Motor caravans | 4 | 3 |
Quads (max unladen weight 400kg - for goods vehicles 550kg and max net power of 15kw) | 4 | 3 |
Dual purpose vehicles | 4 | 3 |
Private hire and public service vehicles (up to 8 seats) | 4 | 3 |
Ambulances and taxis | 4 | 1 |
Private passenger vehicles and ambulances (9 to 12 passenger seats) | 4 | 1 |
Goods vehicles (up to 3,000kg design gross weight) | 4 | 3 |
Class 4 vehicles (9 to 12 passenger seats) with a seat belt installation check | 4a | n/a |
What are the Class 4 MOT bay dimensions?
MOT Bays come in various shapes, sizes, and designs depending on the class of vehicles that needs to be MOT tested on each premise.
The length of the Class 4 MOT bay will be dependent on your choice of equipment, as well as the size, type and layout of the premises, and for this reason, we recommend a visit to your premises from one of our MOT experts to have your potential MOT Bay measured and planned out correctly along with advice and guidance on the MOT equipment that you will need for a Class 4 MOT Bay, along with any additional requirements you would like to include.
However, we have written a blog on the subject to give you an insight into the size requirements for a Class 4 MOT Bay.
